Mcb Distribution Board
Overview
MCB Distribution Board functions as a protective enclosure which receives incoming electrical power before it distributes the power to multiple circuits that each have their Miniature Circuit Breaker as protection. The electrical installation point divides the incoming feed into separate outgoing circuits which have individual protection systems that deliver power to different building areas and floors and equipment.
Our MCB distribution boards create a structure which supports multiple MCBs and copper busbars and neutral links and earthing arrangements through the use of MS and GI sheets that have a powder-coated finish. The internal design creates sufficient space for wiring while establishing distinct circuit separation, which improves the process of installation and inspection and future electrical system modifications.
We supply MCB Distribution Boards in India from our manufacturing facility to contractors, builders, electrical consultants, and wholesalers across the country. As established MCB Distribution Board Manufacturers in India, our range covers SPN and TPN configurations, single door and double door variants, and circuit capacities suited for residential, commercial, and industrial applications.
Those looking for dependable MCB Distribution Board Suppliers in India, can reach us for standard configurations, custom builds, bulk quantities, and pan-India delivery.
Product Specifications
| Parameter | Details |
|---|---|
| Material | M.S. Sheet / G.I. Sheet |
| Sheet Thickness | 1.0 mm / 1.2 mm / 1.6 mm |
| Configuration | SPN / TPN |
| Door Type | Single Door / Double Door |
| Circuit Capacity | 4 Way to 24 Way (customisable) |
| Busbar | Copper Busbar |
| Mounting Type | Surface / Flush / Recess |
| Finish | Powder Coated |
Key Features
- Designed to distribute incoming power across multiple individually protected circuits.
- Made from M.S./G.I. sheets so as to provide structural stability and support in excess of 80 years.
- Comes with copper busbar, neutral link, and earth link as standard fitment.
- Ample internal wiring area and adequate separation between circuits allow for neat installations.
- Design will meet all current IS8623 / EC61439 standards.
